6005 aluminum sheet is Al-Mg alloy, is the most widely used a rust-proof aluminum, the use of a wide range of alloys, especially the construction industry is inseparable from the alloy, is the most promising alloy, can not heat treatment enhanced, polished.

  6005 Aluminum sheet Chemical Composition

AlloyTemperThickness(mm)Width(mm)Length(mm)Typical products
6005 Aluminum SheetO, T4, T6, T6510.3-600500-2600500-16000Car fuel tank,Traffic vehicles

  6005 Aluminum Sheet Chemical Composition

Aluminium: 97.5 to 99.0%

Chromium: 0.1% max

Copper: 0.1% max

Iron: 0.35% max

Magnesium: 0.4 to 0.6%

Manganese: 0.1% max

Silicon: 0.6 to 0.9%

Titanium: 0.1% max

Zinc: 0.1% max

Residuals: 0.15% max

  6005 Aluminum Sheet Typical material properties:

Density: 2.70 g/cm3, or 169 lb/ft3.

Young‘s modulus: 69 GPa, or 10 Msi.

Ultimate tensile strength: 190 to 300 MPa, or 28 to 44 ksi.

Yield strength: 100 to 260 MPa, or 15 to 38 ksi.

Thermal Expansion: 23 μm/m-K.

6005 Aluminum Sheet Packing

Packing Details : Standard export package.
Aluminium Sheet of packaging meet the export standard. Plastic film and brown paper can be covered at customers’ need. wooden case or wooden pallet is adopted to protect products from damage during the delivery.
6005 Aluminum Sheet Packing
6005 Aluminum Sheet Packing
6005 Aluminum Sheet Packing
6005 Aluminum Sheet Packing

Applications for 6005 Aluminum Sheet

1, 6005 Aluminum Sheet with good corrosion resistance, excellent weldability, cold workability is better, and with moderate strength;

2, High strength, especially with anti-fatigue strength, plasticity and high corrosion resistance;

3, good forming processing performance;

4, HuaWei Aluminum has semi-continuous casting production line 6, continuous casting and rolling production line 10, other large-scale processing equipment 44, the annual output reached 450,000 tons, 6005 aluminum plate for large-scale production provides a solid foundation;

About us

Henan Huawei Aluminum Co., Ltd. is the leader of many aluminum manufactures and suppliers in China. We strictly control the quality and focus on customers. We hope to have in-depth cooperation with you and provide you with high quality aluminum material products custom OEM services. If you want to get the newest and best prices by per kg or per ton standard weight, please contact us.


Standrad export seaworthy wooden pallet with

  1. Plastic film protection.
  2. Hard Kraft Paper.
  3. Steel Bar Bunch.
  4. Wooden plate.
